Optec Alnitak Flip Flat- up to 8 1/8in
Designed as a combination dust cover and flat field calibration lamp, Alnitak Astrosystems' flagship product, the Flip-Flat, utilizes a remotely controlled motorized arm and electroluminescent lamp, providing convenience and precision calibrations for refractors up to 6-inch (155mm) diameter.
- Lamp Diffuser Diameter: 7.7" (195mm)
- Lamp Illumination Diameter: 6.7" (170mm)
- Control Box Dimensions: 2.25" x 3.15" x 4.2" (57 x 80 x 106mm)
- Weight: 1 lb. 6 oz. (0.6 kg)
- Lamp Pivot Arm: 6.1" (155mm) length
- Range of Pivot Arm: 95-degrees
- Power requirements: 5VDC provided by USB interface
- Minimum OTA/dewshield OD: 4" (stock #19050)
- Maximum OTA/dewshield OD: 8.125" (stock #19052)
- Alnitak Software Compatiblity: Windows XP, Vista, Windows 7 and 8.
- Command Line Program: AACmd.exe
All part# note: the diameter of the fully illuminated lamp for each of the Flip-Flat models is 6.7" or 170mm, regardless of the model purchased. To accomodate the smaller 4" to 6" OTA's, a spacer is added to the mounting bracket which better centers the lamp over the OTA. For the larger OTA, the bracket is machined down and an oversized ring is added to block any stray light from interferring with the flat lamp.
